Flex Grip Kit

NO LIMIT. JUST CREATIVITY!

The Flex Grip Kit a unique modular system which consists primarily of 2 components: Base Plate and Legs.

Flex Grip Kit





NO LIMIT. JUST CREATIVITY!

The Flex Grip Kit a unique modular system which consists primarily of 2 components:

Base Plate and Legs


BASE PLATE

The Base Plate features a bubble level as well as versatile holes and threads for various purposes.



LEGS

All legs are identical and can be extended to your requirement. They have a flexible ratchet to cover different angles, made for difficult setups. Each leg can except a seat or any kind of accessories (e. g. lamp).

No Limit – Just Creativity!





VERSATILE

It is a universal tool for multi-purpose use and can be extended according to your needs.


 Get big already with the standard kit!



The Flex Grip Kit covers following product categories:

  • Table Dolly (linear, curve + freestyle)
  • LowBoy / HiHat
  • Bazookabase (3-12 legs)
  • Camera Base
  • Rigging System (tubes 33-50mm)
  • Slider (on ground or tripod)
  • Tracking Dolly (36 + 62cm gauge)
  • Doorway Dolly (with Tire Set and steering)



TABLE DOLLY

The Table Dolly is one variant of the lovely Flex Grip Kit which allows great camera moving on smooth surfaces, for example a table.

The Base Plate can be individually combined with a bowl (75 – 150 mm), mitchell- or wedge-tilt-plate or directly a fluid head with an integrated M10 thread in the middle (see picture – without bowl).


LOW BOY / HI HAT

The LowBoy / HiHat can be equipped with 75 – 150mm bowl or with a Mitchell Plate.

Leveling feet can be placed directly to the Base Plate or for bigger footprint, to extension legs. The internal bubble level always keeps you safe!

BAZOOKA BASE

It can be set up with 3 or more (up to 12) legs. The flexible design with the ratchet makes tough situations easy.

High payload capacity of up to 250kg (550lbs) is achieved due to strong, high grade aluminium.
The Flex Grip Kit becomes a Studio Dolly if used with studio wheels.

CAMERA BASE

In combination with a rotating seat, the Flex Grip Kit becomes a Camera Base for e. g. sport events.

SLIDER

Normally, sliders are limited by the length of their rail. Not with the FlexGripKit!
You decide the lenght due to a railsystem which can be extended to your needs. It can also be combined with curved rails.

LIGHTWEIGHT

A high grade aluminium tube wheighs only 1,9kg (4lbs) and has a length of 1,5m. Special length upon request.

Odoo - Sample 1 for three columns

RIGGING

Using the same ratchet connection of the legs, the clamp is ready to be used for scaffold mounting or rigging. This clamp is designed to hold all tubes with diameters from 33mm to 50mm and can be rotated in two axis.

Odoo - Sample 2 for three columns




To add a fourth column, reduce the size of these three columns using the right icon of each block. Then, duplicate one of the column to create a new one as a copy.

Odoo - Sample 3 for three columns


GAUGE

The FlexGripKit slider can be operated on 36cm or 62cm gauge.

Just extend your FlexGripKit Base Plate with 4 additional legs.


SKATEBOARD WHEELS

Smooth and silent sliding is guaranteed by using high quality bearings, and an offset positioning of the rubber counted wheels.

PRECISION

Leveling is easy by means of leveling feet if layed down the floor or by simply adjusting the height of the stand if mounted on a higher level.





EXPANDABLE

Extending the Slider is so easy because of the well-designed Flex Grip Kit modular system. As well you can use diverse accessories for example our telescopic push rod.



TRACKING DOLLY

You can convert the Flex Grip Kit to a Tracking Dolly by adding 4 identical platforms. High payload capacity of up to 250kg (550lbs) enables to ride the cameraman and assistant. The standard track gauge of 62cm allows this Tracking Dolly to ride on all common tracks which are standard around the world.


As an option economical and compact rubber tracks  are available.

DOORWAY DOLLY

A further modification would be an upgrade with a tire set. Weighing less than 19kg (42lbs) this Doorway Dolly gives you the freedom you need!
Supreme operation is achieved by using the electrical driven P1 column.

TRANSPORT

Measurements of the small transport case is 66 x 49 x 21 cm (26 x 19 x 8“) and weighs only 7,5kg(17lbs.)






 START RIGHT NOW

The FlexGripKit Standard version consists of:


  • 1x Base Plate
  • 1x Screw
  • 1x Euro Mount
  • 2x Clamp
  • 3x Levelling foot
  • 4x Distance bolt
  • 8x Legs
